Hints: To help with the processing of your request provide the following information about the differential pressure unit you are seeking.
If you have a 20 digit Part Number (example: 20BCXXX0100A1ABAXX01), supply that number, and that will cover all specifications needed. If you don't have that number please supply as much of the following information as you can. Model Number (199,200,224,226,227,247,251,284,285,273,274,288,289,316,318) Housing Material (Forged Brass, Cu Ni 70/30, Brass, Steel, CRES, Monel, Special.) Bellows Material (Be Cu, Inconel 625, 316 SS.) Pressure Connections :
1/4" NPT 500-1500 SWP 7/16"-20 UNF-28 Filled System 2" BeCu Hsg. & Tube Filled System 2" CRES Hsg. & Tube Filled System 4" CRES Hsg. & Tube Filled System 4" CuNi Hsg. & Tube 1/2" NPT Top-1/4" Bot. 3000 & 6000 SWP 1/4" NPT Top-1/2" Bot. 3000 & 6000 SWP Filled System 2" Inconel sensor, CuNi- Hsg. & Tube Filled System 4" Inconel sensor, CuNi- Hsg. & Tube Special (please specify)
Specify Differential Pressure Range. Specify Units of Pressure. (Inches of water, PSID, PSIA, ect.) Specify Dial Type: (zero left, center zero, zero right, blank white, or special) also specify whether dial is black with white markings or white with black markings. Does unit have any switches? (singe, dual, or none) Does unit have a red set pointer? Does unit require O2 cleaning? Does unit require cleaning for nuclear service?
|
|
